Regula 4305DMH
Regula 4305DMH

The Regula 4305DMH is an advanced second line forensic spectral comparator with 21 integrated light sources, a digital 4Mpx camera, 100x on screen magnification.  This system captures, stores and compares high resolution images for forensic examination.

The device has a spacious working area over the object stage, clamps for fixing examined documents and a special shield protecting from harmful effects of ultraviolet radiation.

The device is operated via the front panel with control buttons or/and Regula forensic studio software. The control buttons are responsible for the activation of light sources and adjustment of camera parameters in different examination modes. The latter are displayed on the LCD display.



Video spectral comparator Regula 4305DMH is equipped with a torch and a modified 10x magnifier Regula 1003M with two white light sources. The front panel of the device has a port for connection of a UV bottom lighter, three available USB-2.0 ports — for additional external devices, such as a spectral luminescent magnifier Regula 4147 used in anti-Stokes examination, thermostage Regula 4168 or a magneto-optical visualizer Regula 4197.



Features

  • Magnification up to 200x (for 30 inch monitor)
  • Connection interface — USB 3.0
  • Protective shields against harmful UV radiation
  • Big size/thick documents examination option
  • Possibility to use with additional equipment (magnetic ink visualizer Regula 4197, spectral luminescent magnifier Regula 4177 and information reference systems on travel documents and banknotes





Functionality

  • Obtaining and processing of images
  • Reading of RFID tags
  • Examinations under high magnification on different levels:
    • protection of the document basis
      • paper opacity, watermarks, security fibers, planchettes, security threads, foil stamping, pole feature, all types of windows, transparent varnish coating, shadow images, etc.
    • printing methods
      • ‌intaglio: texts, guilloche frames, rosettes and vignettes, microprinting, latent images and moire patterns, signs for the visually impaired, blind embossing, colour shifting ink, including OVI with embossing and latent images, etc.
      • letterpress: serial numbers, texts, barcodes, etc.
      • ‌offset printing including Orlov and rainbow printing: texts, microprinting, moire patterns, background and anti-copy patterns, etc.
      • ‌screen printing: security features with optically variable effects, etc.
      • see-through register
      • perforation
    • physicochemical protection
      • ‌anti-Stokes luminescence
      • UV luminescence with different wavelength
      • ‌IR luminescence
      • security features with magnetic properties, etc.
    • complex security features
      • ‌holographic images, OVD
      • retroreflective protection
      • security features with IR-metameric ink
      • special polymer coating of security laminates
      • metallized coating
      • laser engraving
  • Additional examination of:
    • fragments of document images depending on the degree of absorption or reflection of IR light
    • document alterations such as erasure, etching etc.
    • traces of signature forgery
    • extraneous lines (do not originally belong to the examined object) that are performed with IR opaque inks
    • blurred, crossed out entries, texts and images
    • document mechanical defects such as cuts, tears, folds, etc.
  • Optionally: detection of security elements with magnetic properties; including blurred and crossed out texts by Regula 4197



Application

  • Border control and immigration services
  • Customs authorities
  • Law-enforcement agencies
  • Forensic laboratories
  • Financial institutions
  • Other agencies and organizations authorized to check documents
  • Document examiners





Specifications














Additional optional accessories





1. Spectral luminescent magnifier Regula 4147

Light sources:
  • incident white
  • 2 high-intensity infrared 980 nm: spot and flood



Field of view, mm ― 11,1×8,1

Sensor:

  • type — CMOS
  • megapixels — 3,1:
    • resolution, ppi — 4700
    • frame size, pixels — 2048×1536
  • dynamic range, dB — 61



Camera filters — IR high-pass with threshold, nm — 660

Connection interface — USB 2.0

Dimensions (length×width×height), mm, not more than — 94×62×52

Weight, kg, not more than — 0,2

Power supply voltage, V — 5

Power consumption, W, not more than — 12,5

Incident white High-intensity infrared 980 nm: spot High-intensity infrared 980 nm: flood



2. Thermostage Regula 4168

Functionality

  • Examination of images and elements of banknotes and travel documents containing thermochromic ink at different temperatures.
  • Examination of a composite security feature Feel®-ID developed by Giesecke & Devrient company. Feel®-ID is based on optically variable and thermochromic effect.



Temperature range, ˚С — +30...+80 with a step of 1 ˚С

Heated area (length×width), mm — 78×48

Dimensions (length×width×height), mm — 170×78×16

Weight, kg — 0,25

Power supply voltage: powered by the USB port of the video comparator, V — 5

Power consumption, W, max — 15

Temperature +20 ˚С Temperature +35 ˚С Temperature +50 ˚С



3. Visualizer of magnetic properties Regula 4197

Functionality

  • Examination of magnetic security features in banknotes and travel documents in the mode of live video
  • Visualization of magnetically hard and magnetically soft materials
  • Possibility to distinguish magnetic inks by residual magnetization
  • Carrying out non-destructive examination of objects with “hard” magnetic properties
  • Reading latent magnetic strokes and codes
  • Examination of damaged documents: reading blurred and crossed out texts printed with magnetic ink
  • Possibility to take magnetic ink intensity measurements in tesla (T)



Field of view, mm — 14×18

Spatial resolution of the optical input system, mkm:

  • frame size 1024×1280 pixel — 14
  • frame size 512×640 pixel — 28



Connection interface — USB

OS — Microsoft Windows XP (SP3), Windows Vista, Windows 7, Windows 8

Dimensions (length×width×height), mm — 59×113×50

Weight, kg — 0,49

Power supply voltage from a USB port, V — 5

Power consumption, W, max — 2,5

Белый верхний
 Черно-белое изображение. Изображение в цвете (картина интенсивной намагниченности). Необработанное изображение.

Black & White. Colour (magnetization intensity pattern). Raw.
